Canon C70

description features specifications includes

Canon’s first compact hybrid DSLR and Digital Cinema Camera, the Canon C70 packs a full feature set into a very compact handheld form factor. Featuring the same DGO (dual gain output) S35mm imager as the Canon C300 Mark III, the C70 has incredibly clean shadows while maintaining a high dynamic range capture regardless of your chosen ISO. Able to reach speeds of up to 120fps in UHD, the C70 records effortlessly to small SDXC cards. Tucked behind the C70’s native RF mount is up to 10 steps of internal motorized ND for exposure control, and hidden behind the fully articulating touch screen display are on board audio controls. The Canon C70 has excellent Dual Pixel Autofocus with touch to track and face detection. The Canon C70 is not only small in size but also in power consumption and can record for approximately 3 hours on one small BP-A30 battery.

Download Manual
  • Dual Gain Output Image Sensor
  • Widely Adaptable RF Lens Mount
  • Full EF Lens Support Through Mount Adapters
  • Built In Motorized ND Filters (2,4,6,8 and 10 Stops)
  • DIGIC DV7 Image Processor
  • 10 Bit 4:2:2 Intra Frame and Long GOP Recording
  • High Frame Rate Recording up to UHD 120fps
  • Canon Log 2, Canon Log 3, PQ and HLG Recording Modes
  • Dual Pixel CMOS Autofocus With Touch to Track and Face Detection
  • Touch Screen Control
  • Mounting Points For Vertical Image Capture
  • Two Mini XLR/TA3 Audio Inputs With Onboard Audio Controls
  • Timecode Input/Output Connector
  • Electronic Image Stabilization
  • Auto ISO
  • LUT Import
Image Sensor
Sensor Size 26.2 x 13.8 mm (Super35)
Sensor Type CMOS
Sensor Resolution Actual: 9.6 Megapixel (4206 x 2280)
Effective: 8.85 Megapixel (4096 x 2160)
Sensor Windowing 2K (2048 x 1080) in 16:9 When Recording in Super 16
Pixel Pitch 6.4 µm
Color Filter Bayer
Shutter Type Rolling Shutter
ISO 100 to 102,400
Gain -6 to 54 dB (Native)
-2 to 54 dB (Expanded)
Advertised Dynamic Range 16 Stops
Camera
Lens Mount Canon RF
Lens Communication Yes
Shutter Speed 1/12 to 1/2000 sec (In 60p Mode)
1/15 to 1/2000 sec (In 50p Mode)
Shutter Angle 11 to 360°
Built-In ND Filter Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64), 8 Stop (1/256), 10 Stop (1/1024) ND Filters
Built-In Microphone Type Stereo
Mono
Media/Memory Card Slot Dual Slot: SD/SDHC/SDXC
Variable Frame Rates DCI 4K: 12 Up to 120 fps
DCI 2K (Windowed): 12 Up to 180 fps
Internal Recording
Recording Modes XF-AVC 4:2:2 10-Bit:
4096 x 2160p at 23.98/24/25/29.97/50/60 fps (24 to 410 Mb/s)
4096 x 2160i at 50/59.94 fps (24 to 410 Mb/s)
3840 x 2160p at 23.98/24/25/29.97/50/60 fps (24 to 410 Mb/s)
3840 x 2160i at 50/59.94 fps (24 to 410 Mb/s)
2048 x 1080p at 23.98/24/25/29.97/50/60 fps (24 to 410 Mb/s)
2048 x 1080i at 50/59.94 fps (24 to 410 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/50/60 fps (24 to 410 Mb/s)
1920 x 1080i at 50/59.94 fps (24 to 410 Mb/s)
1280 x 720p at 23.98/24/25/29.97/30/50/59.94 fps (24 to 410 Mb/s)
1280 x 720i at 50/59.94 fps (24 to 410 Mb/s)
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit:
4096 x 2160p at 119.88/120 fps
3840 x 2160p at 119.88/120 fps
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit:
2048 x 1080p at 179.82/180 fps
1920 x 1080p at 179.82/180 fps
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit:
2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s)
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit:
4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps (135 to 225 Mb/s)
3840 x 2160p at 50/59.94 fps (135 to 225 Mb/s)
2840 x 1080p at 23.98/24/25/29.97/50/59.94 fps (50 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps (50 Mb/s)
1280 x 720p at 50/59.94 fps (12 Mb/s)
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 10-Bit:
4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps (100 to 170 Mb/s)
3840 x 2160p at 23.98/24/25/29.97/50/59.94 fps (100 to 170 Mb/s)
2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)
1280 x 720p at 50/59.94 fps (9 Mb/s)
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit:
4096 x 2160p at 119.88/120 fps
3840 x 2160p at 119.88/120 fps
2048 x 1080p at 179.82/180 fps
1920 x 1080p at 179.82/180 fps
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit:
4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps (150 Mb/s)
3840 x 2160p at 23.98/24/25/29.97/50/59.94 fps (150 Mb/s)
2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps (35 Mb/s)
1280 x 720p at 50/59.94 fps (8 Mb/s)
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit:
4096 x 2160p at 119.88/120 fps
3840 x 2160p at 119.88/120 fps
2048 x 1080p at 179.82/180 fps
1920 x 1080p at 179.82/180 fps
Gamma Curve Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Wide DR
Audio Recording 4-Channel 24-Bit 48 kHz LPCM Audio
Still Image Support JPEG
External Recording
Video Output 4:2:2 10-Bit via HDMI:
4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps
3840 x 2160p at 23.98/24/25/29.97/50/59.94 fps
1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps
2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps
1280 x 720p at 23.98/24/25/29.97/50/59.94 fps
Interfaces
Video Connectors 1 x HDMI Output
Audio Connectors 2 x Mini XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8″ / 3.5 mm Stereo Input
1 x 1/8″ / 3.5 mm Stereo Headphone Output
Other I/O 1 x USB Type-C Control, Video Input/Output
1 x BNC Timecode Input/Output
1 x 2.5 mm LANC Control
Display
Display Type Articulating Touchscreen LCD
Size 3.5″
Resolution 2,760,000 Dot
EVF
EVF Optional, Not Included
Power
Battery Type Canon BP-A Series
Power Connectors 1 x Barrel (11.5 to 20 VDC) Input
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C (Recommended)
Operating Humidity 85% (Recommended)
General
Tripod Mounting Thread 1/4″-20 Female (Bottom)
1/4″-20 Female (Side)
Dimensions 6.3 x 5.1 x 4.6″ / 160 x 130 x 116 mm
Weight 2.58 lb / 1.17 kg

Camera Body
RF Mount Port Cap
(2) 15mm Aluminum Medium Rods
WC Top Plate & Top Handle
WC Accessory Rod Bracket
3 Piece Microphone Mount
WC 15mm LWS Baseplate
WC Arca Swiss & Quick Dovetail
(3) BP-A30 Batteries
CG-A20 Battery Charger
CA-CP200 AC Adapter & AC Cable
5/32 T Handle Allen Wrench
(2) LP XLR3F to TA3M Cable
Hyperthin HDMI Type (A) – (A) Cable
SDXC UHS II Card Reader
USB 3.1 Type C to Type C Cable
USB 3.1 Type C to Type A Cable
