SmallHD Cine 13 4K High-Bright 13″ Monitor

description features specifications includes

The SmallHD Cine 13 is a 13-inch 4K high-brightness production monitor featuring a 1500-nit daylight-viewable screen and a versatile “Unibody Smart Chassis” for rigging accessories. It supports critical on-set monitoring with multiple 12G-SDI and HDMI inputs/outputs and runs on the PageOS 4 software platform which offers customizable workflows and monitoring tools. Its design prioritizes portability and power flexibility with a lightweight build and hot-swappable dual battery plate options.

  • 13.3″ Display, 3840 x 2160 4K Resolution
  • 1300:1 Contrast, 10-Bit Color
  • 1500 cd/m², Edge-Lit Display, PageOS 4
  • 12G-SDI & HDMI 2.0 Inputs/Outputs
  • 3D LUT Support, SD Card Slot
  • Dual Hot-Swappable Power Input
  • Two 2-Pin & 3 x USB-A Power Outputs
  • Dual and Quad View, 100% Rec.709 Color
  • Waveform, False Color, Focus Assist
  • Peaking, Pixel Zoom, Pages, Page Tabs
Display
Panel Type
LCD
Display Size
13.3″ / 33.8 cm
Native Resolution
3840 x 2160
Aspect Ratio
16:9
Touchscreen
No
Maximum Brightness
1500 nits / cd/m2
Color Support
1.07 Billion Colors (10-Bit)
HDR Support
No
Color Gamut
100% Rec. 709
Image Controls
False Color, Focus Assist, Focus Peaking, Pixel Zoom, Waveform
Inputs/Outputs
Video I/O
1x HDMI 2.0 Input
4x BNC (12G-SDI) Input
1x HDMI 2.0 Output
4x BNC (12G-SDI) Output
Embedded Audio
HDMI
SDI
Audio I/O
1x 1/8″ / 3.5 mm Headphone Output
Built-In Speaker
No
Power I/O
1x XLR 4-Pin (34 VDC / 12 A) Input
2x LEMO 2-Pin (12 VDC / 2 A) Output
1x USB-A (5 VDC / 2.4 A) Output
1x USB-A (5 VDC / 1.5 A) Output
1x USB-C (5 VDC / 1.5 A) Output
Other I/O
1x RJ45 (GPI) Input/Output
1x RJ45 (LAN) Input/Output
Media/Memory Card Slot
Single Slot: SD/SDHC [LUT Upload Only]
Format Support
Video Format
HDMI
DCI 4K: 60
SDI
UHD 4K: 60
Power
Input Power
12 to 34 VDC at 18 A
Battery
Interchangeable Mount (No Plate Included)
Power Consumption
210 W (Maximum)
Mounting
VESA Mounting-Hole Pattern
Unspecified VESA Pattern
Tripod/Accessory Mounting
Left/Right
1x 1/4″-20 Female
Top
2x 1/4″-20 Female
Top/Left/Right
2x 3/8″-16 Female
Bottom
8x 1/4″-20 Female
General
Operating Conditions
32 to 100°F / 0 to 37°C
Storage Conditions
0 to 105°F / -17 to 40°C
Dimensions
13.2 x 10.1 x 2.3″ / 33.5 x 25.7 x 5.8 cm
13.2 x 12.4 x 4.7″ / 33.5 x 31.5 x 11.9 cm (Including Feet, Handle)
Weight
6.8 lb / 3.1 kg
  • Cine 13 Monitor
  • Locking Screen Protector
  • Dual Gold Mount Battery Plate
  • VESA Mount Base
  • SD Card
  • 24V Power Supply
  • AC Cable
  • Sun Hood (2 Pieces)
  • (4) Thumbscrews w/ Zipper Bag
  • Articulating Monitor Mount
